Hot Door CADtools v12.1.1 CR2

Hot Door CADtools v12.1.1 and Control Plug-ins v1.7 ONLY for Ai24 CR2

CADtools – Precision drawing and dimensioning power inside Adobe Illustrator.Click and drag dimensions or labels on every possible object, path, or point in space. Live dimensions follow and respond to artwork changes.

CADtools adds 92 tools to the tool panel. Red dots indicate the number and placement of mouse-clicks to edit or create an object, label or dimension. New tools include Scale Line, Repeat, Repeat Along Path, Scaled Type, Grid, and Wave tools.

Control Plug-ins:

• ArtLabel 1.7.0
• ArtTags 1.7.0
• DocLabel 1.7.0
• FixPix 1.7.0
• NitPicker 1.7.0
• ParticuLayer 1.7.0
• TimeSheet 1.7.0

What’s New:

CADtools 12.1.1 release notes

• Fixed rare crash at launch
• Fixed copy and paste of dimensions into new documents
• Fixed CADlabels Detach button
• New hidden preference “FocusFieldPostTransform” added to allow CADtracker and CADaxonometric transform fields to stay focused after a transform
• Fixed random panel stretching when using non-100% UI scaling
• Fixed Bezier Length dimensions from disappearing after rotation
• Fixed dimension locking and hiding when using the Layers panel
• Fixed various small UI drawing issues

Compatibility: macOS 12 or later 64-bit
Homepage https://www.hotdoor.com/

Screenshots
